FlackTec Medium SpeedMixer
FlackTec Medium SpeedMixers

Medium SpeedMixers

This product range includes SpeedMixer™ models with mixing weight capacities of up to 1000 g and cup volumes of up to 2800 mL. As always, these SpeedMixers ™ enable rapid, easy mixing and grinding of materials that would otherwise take significant time or effort to homogenize. Models in this range all have the optional capability for programmable vacuum mixing. Recommended for environments that require both small-scale material formulation and scaling up to smaller pilot or specialty production quantities.
Model Maximum Container Volume Maximum Material [per container] Max Speed Size (HxWxD, in.) Machine Weight (lbs) Touch Screen Programs Mixing Zones Vacuum Mixing
DAC 1200-300 1200mL 300g 2300 23x17.2x25.6 230 Yes 250 up to 10 No
DAC 1200-300 VAC 1200mL 300g 2300 25.2x17.2x27.2 244 Yes 250 up to 10 Yes
DAC 1200-500 1200mL 500g 2000 23x17.2x25.6 240 Yes 250 up to 10 No
DAC 1200-500 VAC 1200mL 500g 2000 25.2x17.2x27.2 249 Yes 250 up to 10 Yes
DAC 1400-1000 1400mL 1000g 1600 25.2x17.2x27.2 255 Yes 250 up to 10 No
DAC 1400-1000 VAC 1400mL 1000g 1600 25.2x17.2x27.2 264 Yes 250 up to 10 Yes
DAC 2800-1000 2800mL 1000g 1200 23.6x21x30.1 300 Yes 250 up to 10 No
DAC 2800-1000 VAC 2800mL 1000g 1200 26.5x21x32 320 Yes 250 up to 10 Yes
applications-globales-speedmixer
Lire la suite
FlackTek Small SpeedMixer
FlackTec Small SpeedMixers


Small SpeedMixers

This product range includes SpeedMixer ™ models with mixing weight capacities of up to 200 g and cup volumes of up to 515 mL. These SpeedMixers™ are ideal for R&D, small batch production and rapid material development, as precision mixing on this scale decreases costs and material waste while allowing for easily-repeatable batches. Recommended for environments such as small specialty production, lab screening, QA testing, and R&D iteration.

Technical Specifications

Model Maximum Container Volume Maximum Material [per container] Max Speed Size (HxWxD, in.) Machine Weight (lbs) Touch Screen Interface Programs Mixing Zones Vacuum Mixing
DAC 330-100 330mL 100g 3500 21x12x16 75 no 3 1 Optional
DAC 330-100 Pro 330mL 100g 3500 21x12x16 75 Yes 150 up to 10 Optional
DAC 515-200 515mL 200g 2500 21x12x16 75 no 3 1 No
DAC 515-200 Pro 515mL 200g 2500 21x12x16 75 Yes 150 up to 10 No

applications-globales-speedmixer
Lire la suite
FlackTek Large SpeedMixer
FlackTek Large SpeedMixers

Large SpeedMixers

This product range includes SpeedMixer™ models with mixing weight capacities of up to 20kg per run as well as volumes up to 5-gallon buckets. These SpeedMixers are specifically designed for specialty and pilot production, as well as R&D requiring large batch sizes. Due to production needs, these large SpeedMixers can be fitted with twin baskets where you can mix 2 containers simultaneously. Models in this range all have the optional capability for programmable vacuum mixing. Scaling up for production in the larger SpeedMixers is particularly easy when they are paired with a small or medium-sized SpeedMixer.
Model Maximum Container Volume Maximum Material [per container] Mixing Containers [per run] Max Total Batch Size [per run] Size (HxWxD, in.) Machine Weight (lbs) Touch Screen Programs Mixing Zones Vacuum Mixing
DAC 10000-5000 2.5 gal (10000mL) 5kg 1 5kg 56x64x81 3700 Yes 250 up to 10 No
DAC 10000-10000 Twin 2.5 gal (10000mL) 5kg 2 10kg 56x64x81 3700 Yes 250 up to 10 No
DAC 10000-5000 VAC 2.5 gal (10000mL) 5kg 1 5kg 56x64x81 3800 Yes 250 up to 10 Yes
DAC 10000-10000 VAC Twin 2.5 gal (10000mL) 5kg 2 10kg 56x64x81 3800 Yes 250 up to 10 Yes
DAC 14000-10000 3.5 gal (14000mL) 10kg 1 10kg 56x64x81 3900 Yes 250 up to 10 No
DAC 14000-20000 Twin 3.5 gal (14000mL) 10kg 2 20kg 56x64x81 3900 Yes 250 up to 10 No
DAC 14000-10000 VAC 3.5 gal (14000mL) 10kg 1 10kg 56x64x81 4000 Yes 250 up to 10 Yes
DAC 14000-20000 VAC Twin 3.5 gal (14000mL) 10kg 2 20kg 56x64x81 4000 Yes 250 up to 10 Yes
DAC 20000-10000 5 gal (20000mL) 10kg 1 10kg 59x64x81 4150 Yes 250 up to 10 No
DAC 20000-20000 Twin 5 gal (20000mL) 10kg 2 20kg 59x64x81 4150 Yes 250 up to 10 No
applications-globales-speedmixer

Lire la suite
RoboDAC™, the SpeedMixer Assistant
FlackTek RoboDAC™

RoboDAC™, the SpeedMixer Assistant

RoboDAC offers SpeedMixer users all the standard benefits of SpeedMixer technology but coupled with an automated collaborative robot. This robot likes and works well with people, no need for cages here! This compact-automated unit only takes up the size of a large office desk in your lab but offers you high-throughput mixing and formulation and record keeping.

Automated Superior Mixing & Grinding

  • colloids
  • fluids
  • grease
  • resins
  • inks & paints
  • silicones
  • pastes
  • oils
  • creams & gels
  • emulsions
  • epoxies
  • powders
  • urethanes
  • and more

Your Own Robot

Technicians, chemists, engineers, or scientists should be focused on thinking and formulating, not pressing buttons and loading and unloading a mixer! Remember, the RoboDAC can continue working, even after everyone has gone home for the weekend.

Features Include

  • Automated mixing profile updates – many formulations need different mixing profiles – users apply a printed-adhesive 2D barcode on the bottom of your cup which tells the machine what speeds/times & mixing profile to use for each cup
  • GMP ready: each cup and mix is serialized so that when a process is complete, the user knows and can verify, via stored data, which specific cup underwent what specific mixing profiles speeds/times/dates.
  • Automatic incoming feed/out-going feed – RoboDAC can be programmed to mix all day and all night, as long as there are incoming cups available!
  • Error handling- when a mix is not completed/can not be completed for any reason, the cup is electronically marked and physically stored to the side- this is noted within the mixing datalog. This error handling ensures that only fully and properly processed materials are sent to the outgoing line.
  • 2D barcode can be created to control and work with external automated processes/scans within your facility.
applications-globales-speedmixer
